Aurora Emerald Quad-Head Green DJ Laser

The X-Laser Aurora Emerald brings a new dimension to aerial laser shows with a bold quad-aperture design that delivers intensely bright green beams and dramatic liquid sky effects. By removing the Y-axis, the Aurora Emerald generates wide, stable sweeps that fill entire rooms—making it one of the safest, easiest, and most cost-effective ways to create breathtaking laser displays.
Designed for users of any skill level, the Aurora Emerald features deeply optimized internal patterns, robust brightness, and full 9-channel DMX control. Whether you’re a beginner running demo and sound-active modes or a seasoned professional creating custom shows, the Aurora Emerald offers a powerful, flexible, and safe experience.
Key Features
- Quad-aperture design for maximum liquid sky and aerial beam coverage
- Aurora-optimized patterns, rebuilt for brightness, clarity, and endless variations
- More power & brightness than earlier Aurora models
- 9-channel DMX, Demo & Sound Active modes for flexible control
- Safer aerial effects—cannot scan upward or downward when properly rigged
- Ultra-wide sweep angles fill even the largest venues
- Eligible for the EZ Variance Kit and compliant with U.S. and international safety standards
- Double quality-checked through a 26-point inspection
- X-Laser no-hassle warranty: 6 months for diodes, 1 year mechanical
- Class 3B high-powered laser; FDA Variance required (EZ Variance Kit sold separately)
Perfect For
- Liquid sky effects
- Aerial room-filling beams
- Clubs, concerts, mobile DJs, installations
- Beginners and pros seeking simple, safe, affordable laser impact
The Aurora Emerald is engineered to dominate spaces with vivid, immersive effects—especially when used in multi-unit setups. Safe, compliant, and optimized for performance, it’s the most accessible way to add professional-grade aerial lasers to your show.
Specifications
- Control: 9-channel DMX (3-pin input and output) recommended, Demo and Sound Active modes available via DMX
- Scanners: Open-loop micro stepper motors
- Settings interface: DIP switches
- Color modulation: TTL
- Laser energy: 280mW (0.28W)
- Wavelengths: 532nm green
- Physical: 21.75” x 8.5” x 6”; 9.2lbs
- Housing type: Black anodized 6061 aluminum
- Power draw: 40W typical, 60W peak
- Power: 110V, 3-pin IEC, 3.0A F3AL250V fuse
- Beam divergence: 1.5-3 mRad
- Beam source: Direct-injection DPSS diode
- Cooling: Filtered forced air
- FDA/IEC hazard class: Class 3B
- International safety: IEC 60825-1 ed. 2007
- FDA/CDRH: 21CFR1040.10 and 1040.11(c)
- Canadian safety: CSA C.22.2 No. 60950-1
- EU safety: EN 60825-1, EN 60950
Downloads
| Filename | Document type | File type |
|---|---|---|
| Scan angle reference guide | User Guide |
