Aurora Crimson Quad-Head Red DJ Laser

$1,149.00

The Aurora Crimson delivers bold, dynamic red beams in a quad-aperture design, creating intense liquid sky and aerial beam effects. An ideal entry-level value, it operates solely via DMX for Auto, Sound-Active, or custom 9-channel control.

The X‑Laser Aurora Crimson is a beginner-friendly quad-aperture laser designed to produce vivid red liquid sky and aerial effects for venues holding up to 500 guests. By removing the Y-axis, Aurora Crimson simplifies creating wide, room-filling laser displays while maintaining maximum brightness and safety.

With Aurora-optimized patterns, this DMX-controlled laser delivers impressive aerial effects at a strong value. Its quad-aperture design provides ultra-wide sweep effects that can blanket large aerial spaces, and using multiple units amplifies the visual impact for larger venues.

Control is simple yet flexible: operate in Auto or Sound-Active modes via DMX, or take full creative control with 9-channel DMX programming. Aurora Crimson’s design ensures safer aerial shows by preventing beams from scanning up into the sky or down into audiences when properly rigged.

Every Aurora Crimson is double quality-checked via a 26-point inspection and meets all U.S. safety and quality standards, including FDA Class 3B regulations.

Specifications

  • Control: 9-channel DMX (3-pin input and output) recommended, Demo and Sound Active modes available via DMX
  • Scanners: Open-loop micro stepper motors
  • Settings interface: DIP switches
  • Color modulation: TTL
  • Laser energy: 800mW (0.8W) total power
  • Wavelengths: 650nm red
  • Physical: 21.75” x 8.5” x 6”; 9.2lbs
  • Housing type: Black anodized 6061 aluminum
  • Power draw: 40W typical, 60W peak
  • Power: 110V, 3-pin IEC, 3.0A F3AL250V fuse
  • Beam divergence: 1.5-3 mRad
  • Beam source: Direct-injection DPSS diode
  • Cooling: Filtered forced air
  • FDA/IEC hazard class: Class 3B
  • International safety: IEC 60825-1 ed. 2007
  • FDA/CDRH: 21CFR1040.10 and 1040.11(c)
  • Canadian safety: CSA C.22.2 No. 60950-1
  • EU safety: EN 60825-1, EN 60950

Downloads

Filename Document type File type
Aurora Series Manual User Manual PDF
